deutschKA Compact Systems
Low space requirement and simple installation
The platform of the "KA" series is a universal carrier system for round vibrators, trough vibrators, dryers, centrifuges and screening stations.
The platform is completely pre-assembled in the manufacturing plant together with the ordered individual systems. There is no need for cost-intensive factory assembly at the customer's site. Individual switchgears are combined in a central switchgear and delivered as a combination. Various sizes and customer-specific designs are available.
Advantages of our KA compact units:
- Compact design: All components integrated on one platform
- Plug&Play: No time-consuming assembly necessary. Pre-assembled at the factory and ready for operation within a very short time.
- Mobile: Can be relocated within minutes
- Little space required
- Can be assembled individually
- Can be moved to new locations
Technical specification - Trough vibrators
TV Trough Vibrator, KF200MP Cleaning Casdcade, ZS21 Centrifuge, SA Sound Isolation Cap
| KA11 | KA32 | KA34 | KA55 | ||
| Total length (A) | mm | 1600 | 1995 | 1995 | 2350 |
| Total width (B) | mm | 1350 | 1500 | 1702 | 1840 |
| Total hight (C) | mm | 1980 | 1980 | 1980 | 1980 |
| Total hight with SA (D) | mm | 1755(TV25) 1920(TV45) | 1920(TV45) 2265(TV55) | 1920(TV45) 2265(TV55) | 2265(TV55) |
| Combinations | |||||
| TV25, KF200 MP | X | ||||
| TV25, KF200 MP, SA | X | ||||
| TV25, ZS21 | X | ||||
| TV25, ZS21, SA | X | ||||
| TV45, KF200 MP | X | ||||
| TV45, KF200 MP, SA | X | ||||
| TV45, ZS21 | X | ||||
| TV45, ZS21, SA | X | ||||
| TV55, KF200 MP | X | ||||
| TV55, KF200 MP, SA | X | ||||
| TV55, ZS21 | X | ||||
| TV55, ZS21, SA | X | ||||
| Separation system manual | X | X | X | X | X |
| Separation system
with motor | X | X | X | X | X |
Technical specification - Circular Vibrators
RA Circular Vibrator, RT Circular Dryer, KF200 MP Cleaning Cascade, ZS21 Centrifuge, SA Sound Isolation Cap
| KA65 | KA86 | KA88 | ||
| Total length (A) | mm | 2600 | 3150 | 3150 |
| Total width (B) | mm | 1840 | 1995 | 2350 |
| Total hight (C) | mm | 1980 | 1980 | 1980 |
| Total hight with SA (D) | mm | |||
| Combinations | ||||
| RA11, RT20, KF200 MP | X | |||
| RA11, RT20, KF200 MP, SA | X | | ||
| RA11, RT20, ZS21 | X | |||
| RA11, RT20, ZS21, SA | X | |||
| RA16, RT27, KF200 MP | X | |||
| RA16, RT27, KF200 MP, SA | X | |||
| RA16, RT27, ZS21 | X | |||
| RA16, RT27, ZS21, SA | X | |||
| RA21, RT27, KF200 MP | X | |||
| RA21, RT27, KF200 MP, SA | X | |||
| RA21, RT27, ZS21 | X | |||
| RA21, RT27, ZS21, SA | X | |||
| Separation system manual | X | X | X | |
| Separation system with motor | X | X | X |
