deutschRF Circular Vibrators
Universal and economical
From deburring to rounding edges to high-gloss polishing: circular vibrators are universal vibratory grinding machines that can be used for a wide variety of applications and materials. RF circular vibrators are very universal and are ideal for particularly large or magnetic workpieces. Due to their compact design, RF circular vibrators are particularly inexpensive and therefore economical. The workpieces are usually separated manually for large components; a magnetic separator can be used for magnetic workpieces.
- Round working container with a flat container bottom
- Particularly wide working channel, even with a small total volume: Allows particularly large workpieces to be machined
- Highly wear-resistant, hot-cast special polyurethane protective coating for maximum service life
- Low-maintenance and powerful unbalance motor
<
>
Technical specifications
| RF03 | RF06 | RF08 | RF11 | RF16 | RF20 | RF26 | RF36 | ||
| Volume (gross) | Liter | 130 | 230 | 330 | 430 | 640 | 800 | 1060 | 1460 |
| Drive power max. | kW | 1,9 | 2,5 | 3 | 3 | 7 | 7 | 7 | 11 |
| Outside diameter (A) | mm | 1000 | 1200 | 1350 | 1450 | 1650 | 1820 | 2000 | 2200 |
| Total height (B) | mm | 1020 | 1090 | 1120 | 1160 | 1225 | 1270 | 1300 | 1320 |
| Channel width (C) | mm | 220 | 270 | 340 | 370 | 440 | 470 | 520 | 650 |
| Height of stone outlet (D) | mm | 650 | 650 | 650 | 650 | 650 | 650 | 650 | 650 |
| Channel height | mm | 310 | 370 | 400 | 440 | 480 | 500 | 560 | 600 |
Application Areas
- Large components with complex geometry
- Processing of magnetic workpieces: Discharge by means of a magnetic separator
- Heavy components
- Sensitive components that could be damaged by falling steps
Equipment
Available equipment:
- Increased drive power for ball polishing as well as for special processes
- Frequency-controlled drive with variable speed control
- PLC-controlled electrical switchgear for partially and fully automated system operation and for optimized process control
- Dosing systems for process media and additives
- Circumferential triangular profile to reduce component build-up on the container wall
- Sound insulation concepts such as sound insulation covers and complete enclosures
- Magnetic separator
- Extended process water management concepts (ring showers, distributor nozzles, rinsing systems, washing nozzles, backwash systems, ...)
- Moving partition walls for contact-free vibratory grinding of several components
- Further special accessories (on request)
