deutschWS Separator
Economical and Mobile
For efficient and economical separation of grinding media and workpieces, our separation machines offer the highest performance in a compact design. The machine can be used anywhere thanks to lockable rollers.
- Economic separation of workpieces and grinding media
- Modularly combinable with many slide grinding systems
- Quickly exchangeable screen inserts for a wide range of grinding media
- Mobile use thanks to lockable rollers
- Adaptable to a wide variety of vibratory grinding machines
<
>
Picture Gallery
Technical Specification
| WS25 | WS27 | WS35 | WS45 | ||
| Engine Power | kW | 0,25 | 0,3 | 0,3 | 0,5 |
| High of component-supply* (B) | mm | 610 | 650 | 650 | 700 |
| Output height* (C) | mm | 420 | 420 | 420 | 420 |
| Width of the strainer (D) | mm | 350 | 350 | 500 | 600 |
| Length of the strainer (E) | mm | 880 | 1300 | 1200 | 1400 |
*Custom height adjustment possible
Benefits
- Semi-automatic operation by two unbalance motors
- Economical separation of workpieces and grinding tools even with larger quantities
- The shortest set-up times when changing the sieve plates are made possible by a tool-free quick clamping system
- Integrated drop stages for improved sieving of grinding wheels
- Integrated drop steps for improved sieving
- Fully plastic-lined screening surface to reduce damage to components during the screening process
- Various discharge chutes exactly suitable for every application
Equipment
The following equipment is available for our WS Separators:
- Drive with variable speed control
- Electronic connection within a plant
- Sieve plates in various perforations depending on customer requirements
- Dispensing chutes in various designs and lengths
- Integrated screening of undersize chips
- Scraper, rinsing rings and drop steps for improved separation
