deutschContinuous Dryer
The continuous dryer is suitable for drying your workpieces using hot air. The components are guided through the thermally insulated drying tunnel on a fine-mesh wire link conveyor belt. The temperature and the speed of the conveyor belt can be set individually.
In addition to a high-pressure air curtain, customer-specific adjustments to the system height, the length of the conveyor belt and the heating output are also optionally possible.
<
>
Technical specifications
| DT32 | DT34-1 | DT34 | DT36-2 | DT36-1 | DT36 | DT54 | DT56 | DT56-1 | DT56-2 | ||
| Conveyor belt width (A) | mm | 600 | 600 | 600 | 600 | 600 | 600 | 600 | 1000 | 1000 | 1000 |
| Tape length (B) | mm | 2600 | 3600 | 3600 | 4600 | 4600 | 4600 | 3600 | 4600 | 4600 | 4600 |
| Drying Tunnel length (C) | mm | 1000 | 2000 | 2000 | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 |
| Total height without switchgear (D) | mm | 1350 | 1350 | 1350 | 1350 | 1350 | 1350 | 1350 | 1350 | 1350 | 1350 |
| Total length without discharge chute (F) | mm | 2830 | 3805 | 3805 | 4785 | 4785 | 4785 | 3805 | 4785 | 4785 | 4785 |
| Total length with discharge chute (G) | mm | 3040 | 4015 | 4015 | 4995 | 4995 | 4995 | 4015 | 4995 | 4995 | 4995 |
| Total width without switchgear (H) | mm | 1200 | 1200 | 1200 | 1200 | 1200 | 1200 | 1200 | 1600 | 1600 | 1600 |
| Total width with switchgear (J) | mm | 1625 | 1625 | 1625 | 1625 | 1625 | 1625 | 1625 | 2025 | 2025 | 2025 |
| Total height* without wind curtain (K) | mm | 1550 | 1550 | 1550 | 1550 | 1550 | 1550 | 1550 | 1550 | 1550 | 1550 |
| Lower edge of the conveyor belt (L) | mm | 600 | 600 | 600 | 600 | 600 | 600 | 600 | 600 | 600 | 600 |
| Delivery height* slide (M) | mm | 470 | 470 | 470 | 470 | 470 | 470 | 470 | 470 | 470 | 470 |
| Filling area length (P) | mm | 950 | 950 | 950 | 950 | 950 | 950 | 950 | 950 | 950 | 950 |
| Filling area height* (N) | mm | 920 | 920 | 920 | 920 | 920 | 920 | 920 | 920 | 920 | 920 |
| Total height* with wind curtain (Q) | mm | 1850 | 1850 | 1850 | 1850 | 1850 | 1850 | 1850 | 1850 | 1850 | 1850 |
| Height passage | mm | 300 | 300 | 300 | 300 | 300 | 300 | 300 | 300 | 300 | 300 |
| Max. Temperature | °C | 150 | 150 | 150 | 150 | 150 | 150 | 150 | 150 | 150 | 150 |
| Max. Heating capacity | kW | 24 | 24 | 48 | 48 | 24 | 72 | 48 | 72 | 48 | 24 |
| Control range heating capacity | kW | 24 | 24 | 24-48 | 24-48 | 24 | 24-72 | 24-48 | 24-72 | 24-48 | 24 |
| Total connected load without wind curtain | kVA | 27 | 27 | 53 | 53 | 27 | 80 | 53 | 80 | 53 | 27 |
| Speed conveyor standard | m/min | 1-3 | 1-3 | 1-3 | 1-3 | 1-3 | 1-3 | 1-3 | 1-3 | 1-3 | 1-3 |
| Max. Speed conveyor (on request) | m/min | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 |
* individual height adjustments possible on request. Custom-made products possible on request.
Application Areas
- Air drying of components
- Drying of large components
- Drying of complex geometries
- Heating of components for the later process
- Thermal treatment of components
- Baking of coatings
Equipment
The following equipment is available for DT Continous Dryer:
- Wind curtain for wiping off liquids
- individual height adjustment
- extended conveyor belt
- Increased/reduced tunnel length with different heating power
- Wire link conveyor belt in stainless steel V4A and with a special mesh size
